With the development of modernization, the number of automobiles in my country has increased rapidly. As an important force-bearing part of a car in contact with the ground, whether the wheel is qualified or not is of key significance to driving safety. It is affected by the dynamic torque of the car when starting and braking and also bears the irregular alternating force generated by dynamic loads in different directions such as the turning of the car during driving, the impact of bumpy roads, and road obstacles. Therefore, any part of the wheel needs to be strictly inspected before being put into use.
As one of the major parts of the wheel, the wheel hub is of key importance for the performance of the wheel. The wheel hub production process is low-pressure casting with strong adaptability and many design varieties, but with low production cost. But problems like material spring back and mold wear also occur during the die-casting process. Then it is necessary to use testing methods to inspect the wheel hub to make sure match the CAD model.
Traditional inspection methods will need to take a lot of time and raise the cost of manufacturing. To shorten the inspection time for mass production, our smart portable blue laser 3D scanner- RigelScan Plus could take this challenge very well.
Let's see how ZG RigelScan Plus takes this challenge to meet customer requirements quickly & well.
✅ Non-contact Measurement, flexible to scan the part without any contact on the part surface;
✅ High-Efficiency Scanning speed up to 1,350,000 measurements/s.
✅ The accuracy is up to 0.02mm
✅ User-friendly. Easy to install the device by cable connection, and new users without rich metrology experience can plug and play with simple training.
✅ High Adaptability, which is insensitive to different working environments.
